AW2500B machine Parameters

1. Rigid structure to assure stable working and longer machine life.

2. Italian high speed blade motor for faster profiling and cutting.

3. AC Servo motor and driver for all axis to get faster production with higher precision.

4. High quality linear guide rail, helical rack pinion and gear box in X Y axis to get vibration free even under heavy loading conditions.

5. Automatic lubrication in all axis for smoother working condition and trouble free.

6. Central water tray and movable water tank for easily bed cleaning and environment friendly .

7. Stainless steel parts and covers for anti-rust and bellows covers on XY axis to increase machine life.

8. Strong gantry cross X axis for vibration free.

Model	AW2500B
Working table size	2620×1400mm
Gantry height	455mm
Max engraving sieze (X/Y/Z)	2400×1300×200mm
Blade diameter	300mm
Blade motor power	5.2KW/2840 rpm（Italian Motor ）
Max Cutting Thickness of Stone Slip	75mm
Voltage/Power	380V/8.5KW
XY axis transmission	Servo Motor and Driver + Helical Rack + Taiwan Linear Guide Rail
Z transmission	TBI Ball Screw
Inverter	Delta Inverter
Switches	Schneider switches
Max XY speed	15 m/min
Max Z speed	3 m/min
XY protective cover	Bellows Cover
Blade cooling	370KW Cooling Pump（Circulation Water）
Water proof table	Steel Sink
Lubrication	Self-lubrication System
Cotrol system	NC studio NK-105 Control System
Machine size	213036161770mm
Gross Weight	1900KG

Profiling and cutting on granite, marble, sandstone, ceramic, quartz etc.
